Technical parameters :
Temperature measuring range |
-20 ℃~550℃ |
Temperature resolution |
0.1℃ |
Detector type |
Vanadium oxide uncooled infrared focal ne detector |
Corresponding band |
8~14um |
Pixel size |
12um |
NETD |
<50mK |
Field Angle |
56°x42.2° |
IFOV |
3.8mrad |
Focusing mode |
No-focus |
Temperature measurement accuracy |
±2percent or ±2℃ larger value of the temperature measurement value |
Detector resolution |
256x192 |
Temperature measuring tool |
Center temperature measurement/hot spot tracking |
Image mode |
Thermal imaging dual light fusion picture-in-picture IMIX visible light |
False color |
7 kinds of |
Temperature alarm |
Whole frame high/low temperature alarm |
Photo taking function |
Supported, with temperature data |
Secondary analysis |
配备PC分析软件 ,可对数据Secondary analysis |
Disy size |
2.8LCD（320x240） |
Lighting |
LED fill light |
Other parameters
Store |
Standard with 16GB SD card, support expansion |
Temperature unit conversion |
Celsius/Fahrenheit/Kelvin |
Working hours |
11H@25℃ indoor |
Fall protection |
3m |
Power supply |
Built-in rechargeable lithium battery |
Net weight of product |
522g |
Product size |
222.3x74.7x84.3mm |
