Technical parameters :
The disy screen |
3.5英寸全视角TFTThe disy screen |
Infrared thermal image resolution |
320x240 |
Visible image resolution |
300 megapixels |
LCD resolution |
640x480 |
Field Angle |
56°x42° |
Thermal sensitivity |
0.07℃ |
Thermal image frame rate |
9Hz |
Focusing mode |
Fixed |
Wavelength range |
8~14um |
Emissivity |
0.01~1 Adjustable |
The color palette |
Rainbow/iron red/cold red/white heat/black heat |
Temperature measurement range |
-25℃~450℃（-13℉~842℉） |
Measurement accuracy |
≥300℃+3%; ≥400℃+10% |
Storage medium |
Built-in storage 8G (actual available 6.6G) |
Image format |
JPG |
Battery |
内置可充电,26650锂Battery |
Working hours |
Six to eight hours |
Set the command |
Unit, language, date, time, message |
Language |
Chinese, English, German, Italian |
Other parameters
Automatic shutdown time |
Optional 5/20 minutes or no automatic shutdown |
Operating temperature |
0~45℃ |
Storage temperature |
-20~60℃ |
WIFI设置 |
Support |
Temperature unit conversion |
℃/℉ |
Net weight of product |
596g |
Product size |
248*97*111mm |
