Technical parameters
Temperature measuring range |
-25 ℃~450℃（-13 ℉ ~842℉） |
Infrared thermal image resolution |
220x160 |
Visible image resolution |
300 megapixels |
The disy screen |
3.2英寸全视角TFTThe disy screen |
Field Angle/minimum focal length |
27°x35°/0.5 m |
Thermal sensitivity |
0.07℃ |
Measurement accuracy |
±2℃/±2% |
Emissivity |
Adjustable from 0.01 to 1.0 |
Thermal image frame rate |
9Hz |
Wavelength range |
8um to 14um |
Focusing mode |
Fixed |
The color palette |
Rainbow/iron red/cool/white heat/black heat |
Store |
Built-in 3G |
Image format |
JPG |
Shutdown time |
Optional 5/20 minutes or no automatic shutdown |
USB |
Micro USB 2.0 |
Operating temperature |
0~45℃ |
Store温度 |
-40~60℃ |
Relative humidity |
<85%RH |
Packing specifications
Power supply |
Built-in lithium battery rechargeable |
Net weight of product |
410g |
Product size |
215*89*88.2mm |
The way of packing |
Suitcase cloth bag |
|
|
|
