Measurement error

±(1percentH±0.1)mm H is the thickness

Resolution

0.01mm

Sound speed adjustment range

1000-9999m/s

Operating frequency

5MHz

Operating temperature range

0~40℃

Probe operating temperature

Room temperature type 0~60℃

High temperature type 0~250℃ (need to match high temperature coupling agent)

Lower limit of pipe measurement

Diameter 10mm probe: 20*3mm(steel);

Diameter of 6mm probe: 12*2mm(steel)

Data storage function

There is

Inverse sound speed measurement function

There is

LCD backlight disy

There is

Upper and lower limit alarm function

There is

Low current indication

There is

Automatic shutdown function

There is

Net weight of product

315g (including accessories, without battery)

Product size

146*70*28mm

The way of packing

Color box packing

Standard outer box capacity

12PCS

Standard outer box size

52*43*32.5cm

Standard gross weight of outer box

16.3KG
