Technical parameters
Dc voltage DCV |
Range :6V~1000V Accuracy :± (0.5percent 3) |
Ac voltage ACV |
Measuring range :6V~750V Accuracy: ± (0.8percent 3) |
Ac current |
Measuring range :6A~600A Accuracy :± (2.5percent 30) |
Resistance |
Measuring range :600Ω~40MΩ accuracy :±(0.8percent 3) |
Capacitance |
Range :60nf~30mf accuracy :±(3.5percent 20) |
Frequency |
Range :10Hz~10MHz Accuracy :±(0.1percent 3) |
Temperature measurement |
Range :-20~1000℃ (0~1832℉) |
Diode/on-off test |
There is |
Square wave output |
There is |
NCV measurement |
There is |
All-unit symbol |
There is |
Backlight setting |
Manual/automatic shutdown |
真There is效值测量 |
There is |
Temperature (℃/℉) |
There is |
Flashlight lighting |
There is |
Working environment temperature and humidity |
0~40℃,（<80%RH） |
Other parameters
Maximum disy |
5999 (3 5/6) Disy |
Sampling rate |
Three times per second |
Battery |
2*1.5V AAABattery |
Net weight of product |
195g（含Battery） |
Product size |
178*58.7*30mm |
The way of packing |
The color box |
|
|
|
