Technical parameters
Dc voltage DCV |
Range :600mV~1000V Accuracy :± (0.5percent 5) |
Ac voltage ACV |
Range :600mV~750V Accuracy: ± (0.8percent 5) |
Direct current |
Measuring range :600uA~10A Accuracy :± (1.2percent 3) |
Ac current |
Measuring range :600uA~10A Accuracy :± (1.2percent 3) |
Resistance |
Measuring range :600Ω~60MΩ Accuracy :±(1.5percent 3) |
Capacitance |
Range :10nf~100mf accuracy :±(4.0percent 5) |
Frequency |
Range :10Hz~10MHz Accuracy :± (1.0percent 3) |
Temperature measurement |
Range :-20~1000℃ (0~1832℉) |
Duty cycle |
Range :1~99percent accuracy ± (3.0percent 3) |
NCV measurement |
There is |
Diode/on-off test |
There is |
Data retention |
There is |
Maximum/minimum measurement |
There is |
Temperature (℃/℉) |
There is |
Flashlight lighting |
There is |
Analog bar |
There is |
Other parameters
Maximum disy |
6000 count disy |
Fireline detection |
There is |
Flashlight lighting |
There is |
Jack LED light |
There is |
Battery |
2/1.5V AAABattery |
Net weight of product |
329g |
Product size |
188*88*54mm |
