Technical parameters
Dc voltage DCV |
Range :600mV~600V Accuracy :± (0.5percent 5) |
Ac voltage ACV |
Measuring range :6V~600V Accuracy: ± (0.8percent 5) |
Ac current |
Range :6A~600A Accuracy :± (3.0percent 10) |
Resistance |
Measuring range :600Ω~60MΩ accuracy :±(1.0percent 5) |
Capacitance |
Range :10nf~100mf accuracy :±(4.0percent 5) |
Frequency |
Range :10Hz~10MHz Accuracy :± (1.0percent 3) |
Temperature measurement |
Range :-20~1000℃ (0~1832℉) |
Duty cycle |
Range :1~99percent accuracy ± (3.0percent 3) |
Diode/on-off test |
There is |
NCV measurement |
There is |
All-unit symbol |
There is |
Backlight setting |
Manual/automatic shutdown |
真There is效值测量 |
There is |
Temperature (℃/℉) |
There is |
Flashlight lighting |
There is |
Working environment temperature and humidity |
0~40℃,（<80%RH） |
Other parameters
Maximum disy |
6000 count disy |
Sampling rate |
Three times per second |
Battery |
2*1.5V AAABattery |
Net weight of product |
190g（含Battery） |
Product size |
164*58.4*30mm |
The way of packing |
The color box |
|
|
|
