Technical parameters
Dc voltage DCV |
Range :200mV~1000V Accuracy :± (0.5percent 3) |
Ac voltage ACV |
Measuring range :2V~750V Accuracy: ± (0.8percent 3) |
直流电压 |
Measuring range :20uA~10A Accuracy :± (1.2percent 8) |
Ac voltage |
Range : 20uA~10A accuracy :± (2.0percent 5) |
Capacitance |
Range :20nf~20mf 度:±(5.0%+10 ) |
Resistance |
Range :200Ω~20MΩ 度:±(0.8%+3) |
Frequency |
---- |
Diode/on-off test |
There is |
Triode /hFE |
There is |
NCV measurement |
There is |
All-unit symbol |
There is |
Backlight setting |
Manual/automatic shutdown |
真There is效值测量 |
There is |
Automatic power failure |
There is |
Flashlight lighting |
There is |
Working environment temperature and humidity |
0~40℃,（<80%RH） |
Other parameters
Maximum disy |
1999 (3 1/2) bit automatic polarity disy |
Sampling rate |
Three times per second |
Battery |
9V Battery |
Net weight of product |
311g |
Product size |
182*90*47mm |
The way of packing |
The color box |
