Technical parameters
5.1发射机Technical parameters
Output signal |
125 kHz |
External voltage identification voltage range |
|
| Technical index of temperature measurement | ±2.5℃ |
| The disy screen | LCD, with function disy and bar chart |
Dielectric strength of external voltage |
Max. 400 vAC/DC |
| Overvoltage category | CAT I1I 300 v |
| Pollution level | 2 |
| Power supply | 1x9V,IEC 6LR61 |
| Minimum current | About 31 mA |
Maximum current |
About 115 mA |
| The fuse | F0.5 A 1000 v,6.3x32 mm |
Work |
-10° C to 50° C, maximum relative humidity (non-condensing) of 80percent |
Storage |
-20℃ to 60℃, Max 80percent relative humidity (non-condensing) at altitude |
Altitude |
Maximum 2000m |
Dimensions (height x width x depth) |
|
| Battery free | About 360 g |
| Battery included | About 420 g |
| 5.2接收机Technical parameters |
|
| Tracking depth | Tracking depth取决于介质及具体应用 |
| Unipolar application | About 0 to 2m |
| Bipolar application | About 0 to 0.5 m |
| Single loop | Up to 2.5 m |
Grid voltage identification |
Approximately 0 to 0.4 m |
| The disy screen | LCD, with function disy and bar chart |
Power supply |
6x1.5 VAAA,IEC LRO3 |
Minimum current |
|
| Maximum current | 约89 mA |
| Work | -10° C to 50° C, maximum relative humidity (non-condensing) of 80percent. |
Store |
-20℃ to 60℃, maximum relative humidity (non-condensing) of 80 percent. |
| Altitude | Max. 2000 m |
| Dimensions (height x width x depth) | 24 .5 mmX78 mmX38.5 mm |
| Battery free | About 280 g |
| Battery included | About 350 g |
