Characteristic
TFT True color liquid crystal Disy
Touch screen control
Fast, medium and slow three-stage scanning speed
Cold end compensation
标配MiniUSB接口
Automatic coupling detection
Specify channel scan
Standard ATS42 data acquisition software
8.4V lithium battery power supply
规格
| Dividing sign | Thermocouple: J/K/T/E/S/N/B/R type |
| Basic accuracy | Type K thermocouple
-100℃~ 0℃±1.2℃ 0℃ to 1350℃ ±0.8℃ (Dividing sign不同略有差异,具体可查阅用户手册) |
| Test range | -200℃~1800℃（Test range因Dividing sign不同而有差异） |
| Resolution | 0.1℃ |
| Number of channels | 2 way |
| Scanning speed | 1s/ channel |
| Correction | Per channel error correction |
| Comparator | Up over down over alarm |
| Standard interface | Mini-USB |
| Standard software | ATS42 Data acquisition software |
| Cold end compensation | Accuracy: 0.5℃ |
| Other | 2.8-inch true color 16M color TFT-LCD disy; Touch screen; USB communication, compatible with SCPI instruction set; Switch between Chinese and English; Backlight adjustment; Automatic shutdown |
| Power requirements | Input: 100-240V to 50/60Hz 0.35A Output: 9V 1A DC |
| Size and weight | External dimension (mm) : 90(W)x190(H)x31(D) Weight: 400g |
| Attachment | K型热电偶2支(2米/支) ATL909直流电源适配器 ATL805锂电池 ATL105 USB通讯线 ATS42 Data acquisition software |
Apply
Applicable to household appliances, motors, electric heating appliances, temperature controllers, transformers, ovens, heat protectors, power supply, lighting, electric power,LED and other industries of manufacturers and quality inspection departments on the multi-point temperature test
