Characteristic
7 "TFT true color LCD
The bar chart shows that
High value, low value, average value shows
Cold end compensation
The standard USB disk port supports mass storage devices
Standard RS232C interface and USB interface
Automatic coupling detection
Specify channel scan
Standard data acquisition software
规格
| Dividing sign | J/K/T/E/S/N/B/R |
| Basic accuracy | Type K thermocouple
-100℃~ 0℃±1.2℃ 0℃ to 1350℃ ±0.8℃ (Dividing sign不同略有差异,具体可查阅用户手册) |
| Test range | -200℃~1800℃（Test range因Dividing sign不同而有差异） |
| Resolution | 0.1℃ |
| Number of channels | No. 16 |
| Scanning speed | Fast: 100ms Medium speed: 500ms Slow speed: 1s |
| Correction | Per channel error correction |
| Comparator | Up over and down over alarm, each channel separately set up over and down over value |
| Standard interface | RS232C port USB flash drive port |
| Standard software | ATS47 Data acquisition software |
| Cold end compensation | Accuracy: 0.5℃ |
| Other | TFT-LCD 真彩液晶显示,断偶检测功能,The bar chart shows that,上限值,下限值 平均值显示 |
| Power requirements | Voltage: 85VAC ~ 260VAC, frequency: 50Hz/60Hz, power: 10VA |
| Size and weight | 216(W)x88(H)x300(D) 3kg |
| Attachment | Thermocouple (according to the order model configuration 2 meters/PCS) U disk communication line data acquisition software |
Apply
Applicable to household appliances, motors, electric heating appliances, temperature controllers, transformers, ovens, heat protectors, power supply, lighting, electric power,LED and other industries of manufacturers and quality inspection departments on the multi-point temperature test
