Characteristic
TFT true color LCD disy, three disy fonts.
Fast, medium and slow three-stage scanning speed
Cold end compensation
The standard USB disk port supports mass storage devices
标配MiniUSB接口
Automatic coupling detection
Specify channel scan
Standard AT48 data acquisition software
8.4V lithium battery power supply
规格
| Dividing sign | Thermocouple: J/K/T/E/S/N/B/R type |
| Basic accuracy | Type K thermocouple
-100℃~ 0℃±1.2℃ 0℃ to 1350℃ ±0.8℃ (Dividing sign不同略有差异,具体可查阅用户手册) |
| Test range | -200℃~1300℃（Test range因Dividing sign不同而有差异） |
| Resolution | 0.1℃ |
| Number of channels | 8 way; It can be extended to 128 channels |
| Scanning speed | Fast: 100ms/ channel Medium speed: 500ms/ channel Low speed: 1s/ channel |
| Correction | Per channel error correction |
| Comparator | Each channel separately sets the upper and lower super values |
| Standard interface | RS232C port USB flash drive port USB communication port |
| Standard software | ATS45 Data acquisition software |
| Cold end compensation | Accuracy: 0.5℃ |
| Other | TFT-LCD true color liquid crystal disy, broken couple detection function |
| Power requirements | Voltage: 85VAC ~ 260VAC Frequency: 50Hz/60Hz Power: 10VA |
| Size and weight | 216(W)x88(H)x300(D) Weight: 3kg |
| Attachment | K-type thermocouple 8 PCS (2 m/PCS) data acquisition software CD |
Apply
Applicable to household appliances, motors, electric heating appliances, temperature controllers, transformers, ovens, heat protectors, power supply, lighting, electric power,LED and other industries of manufacturers and quality inspection departments on the multi-point temperature test
