Characteristic
Comparator output: Through the built-in Handler interface,RS232C output more detailed sorting results
Ring: can set all comparator result ring switches.
Users can set GD/NG sound and adjust disy brightness according to their needs
Keyboard lock function.
Built-in interface: Handler interface,RS232C interface.
Compatible with SCPI instruction set, bus data and command transmission using ASCII code, complete all instrument functions. Compatible with IEEE-488.1 and IEEE-488.2.
Multiple trigger modes: internal trigger, manual trigger, external trigger, and remote trigger.
Specifications
| Measurement parameters | Dc resistance |
| Basic accuracy | 0.02% |
| Measuring range | 0.1μΩ～110MΩ |
| Signal source | Current range: 1μA to 1A |
| The range of | 十一The range of自动和手动 |
| Measure the speed of | 167 times per second,60 times per second,10 times per second,2 times per second |
| Show the result | Direct reading,ΔABS,Δpercent and sorting results |
| Maximum reading | 105000 |
| Correction | 全The range of内短路清零 |
| Comparator | 30组Comparator,显示和输出NG-LO, GD-IN, NG-HI 讯响和音量可调 |
| Trigger mode | Internal, manual, external, remote trigger |
| Interface | RS232CInterface HandlerInterface（PLCInterface） |
| Temperature compensation | Accuracy: 0.2 °C range: 0 ~ 80 °C |
| Test end | 4端屏蔽（包括2个检测端和2个驱动端）和外屏蔽地端 |
| Power requirements | Voltage: 198VAC ~ 240VAC Frequency: 50Hz Power: 15VA |
| Size and weight | Outer dimension (mm) : 264 (W)x107(H)x350 (D) Inner dimension: 216(W)x88(H)x323(D) Weight: 4kg |
| Attachment | L501 Kelvin clip ATL801:232 Communication cable |
| 可选Attachment | L620 m Resistance four end Fixture |
| Other | Four color vacuum fluorescent screen VFD disy keyboard lock data retention function |
