Characteristic
High brightness, true color LCD disy
Touch screen
Chinese, English switch
USB-HID通讯
Calibration function: full range of open and short circuit frequency sweep zero.
1300mAh rechargeable lithium battery
Ultra-long working Hours: 14 Hours(@30percent brightness)
Specifications
| Measurement parameters | Inductance L, capacitance C, resistance R, impedance Z, automatic |
| Basic accuracy | 0.2% |
| Test frequency | 100Hz, 120Hz, 1kHz, 10kHz, 100kHz |
| Test the speed | 4 times per second, 1.5 times per second |
| Disy range | L: 0.01uH-9999H
C: 0.01pF - 9999uF R,Z: 0.0001Ω - 99.99MΩ D:0.0001–9.999 Q:0.0001~999.9 |
| Output impedance | 100Ω |
| The reading | Primary parameter: 49999 Secondary parameter: 49999 |
| Signal level | 0.6Vrms, accuracy ±10percent |
| Trigger mode | Internal |
| Comparison mode | SEQ/ABS/PER |
| Calibrate | Zero out |
| File | USB storage |
| Interface | USB-HID communication |
| Communication protocol | SCPI |
| Other functions | Touch screen,Chinese, English switch, 4 级背光灯调节,定时关机 |
| Power requirements | Power adapter/charger: Input: 85-240V AC; 50/60Hz 0.35A Output: 9V 1A DC |
| Size and weight | External dimension (mm) : 90(W)x195(H)x35.5(D)
Weight: 400g |
