Characteristic
High brightness, true color LCD disy
Touch screen
Chinese, English switch
USB-HID通讯
Calibration function: full range of open and short circuit frequency sweep zero.
1300mAh rechargeable lithium battery
Ultra-long working Hours: 14 Hours(@30percent brightness)
Specifications
| Measurement parameters | C-D, C-Q, C-R, L-D, L-Q, L-R, L-Rdc, R-Q, R-X, R-Rdc, Rdc, Z-D, Z-Q, Z-θr, Z-θd |
| Basic accuracy | 0.2% |
| Test frequency | 50 hz, 100 hz and 120 hz, 1 KHZ, 2 KHZ, 10 KHZ, 50 KHZ and - 100 KHZ |
| Test range | Automatic and manual |
| Test the speed | Slow 2.5 times/s, fast 10 times/s |
| Disy range | L: 0.01uH-9999H
C: 0.01pF - 9999uF R,Z: 0.0001Ω - 99.99MΩ D:0.0001–9.999 Q:0.0001~999.9 |
| Output impedance | 100Ω |
| The reading | Primary parameter: 50000 Secondary parameter: 50000 |
| Equivalent mode | Series, parallel |
| Signal level | 0.3V,0.7V and 1.0Vrms accuracy: 10percent |
| Trigger mode | Internal |
| Comparison mode | SEQ/ABS/PER |
| Calibrate | 开路和短路Calibrate |
| File | USB storage |
| Interface | USB-HID communication |
| Communication protocol | SCPI |
| Other functions | Touch screen,Chinese, English switch, 4 级背光灯调节,定时关机 |
| Power requirements | Power adapter/charger: Input: 85-240V AC; 50/60Hz 0.35A Output: 9V 1A DC |
| Size and weight | External dimension (mm) : 90(W)x195(H)x35.5(D)
Weight: 400g |
