Characteristic
Short-circuit test: current 30A, internal resistance 40mΩ
LED load test function
Dynamic test: 10 files,0.1Hz~1kHz
Dynamic list test: 10 files,100 steps/file
Comprehensive list test: 10 files,20 steps/file
Battery test: 999.99AH
Global Settings file: 20 groups
Triggers: internal triggers, bus triggers, and external triggers
Interface: Standard RS232C and Handler interface
Programming language: SCPI and simple communication protocol
Disy: 3.5 inch true color LCD
Support 4W remote test function
Specifications
| Rated input | 150W、150V、30A |
| Constant current | 0-3A: Resolution: 0.0001A accuracy: 0.05percent 0-30A: resolution: 0.001A accuracy: 0.1percent |
| Constant voltage | 0-18V: Resolution: 0.001V accuracy: 0.05percent 0-150V: resolution: 0.01V accuracy: 0.05percent |
| Fixed power | 0-100W: Resolution: 0.001W Accuracy: 1percent Above 100W: resolution: 0.01W accuracy: 1percent |
| Constant resistance | 0.1 ~ 99Ω : Resolution: 0.01Ω Accuracy: 1percent 100 ~ 4kΩ : Resolution: 0.1Ω Accuracy: 1percent |
| Monitor | 电压表准确度：0.05%,电流表准确度：0.1% |
| Short circuit test | Current: about 30A; Internal resistance: about 40 Mω |
| Dynamic testing | Test 0.1Hz ~ 25kHz |
| Dynamic list testing | 10 files,100 steps/file |
| Comprehensive test | 10 files,20 steps/file |
| Battery capacity test | MAX 999AH |
| Interface | RS232CInterface |
| 可选Interface | RS485Interface |
| Protect | 5级安全Protect |
| Other | 3.5 "true color LCD disy,4W remote test, intelligent fan cooling |
| Power requirements | Voltage: 220VAC frequency: 50HZ Power: 20VA |
| Size and weight | External dimension (mm) *264 (W) *107 (H) *350 (D) Weight: 5Kg |
| Attachment | ATL509 Test Cable |
