Characteristic
High brightness, super clear four color VFD disy, a variety of parameters disy at the same time
Charge test automatic switch.
Peak hold function.
Full range open circuit zero clearing function.
Comparator output: The sorting result can be output through RS232C or Handler interface
Audible: Audible switch can be set.
Adjustable sound and disy: You can set GD/NG sound and trigger modes as required: internal trigger, manual trigger, external trigger, and remote trigger.
Adjust the disy brightness
Optional foot switch.
Specifications
| Measurement parameters | Leakage current |
| Basic accuracy | 1% |
| Output voltage | 10V～170VDC |
| Test range | Current: 0.1uA~20mA Without aging test current: 160 mA |
| The reading | 9999 |
| The range of | 六The range of自动和手动 |
| Charging current | 500mA(MAX)/1.5A（MAX） |
| Test the speed | 20 times per second |
| Show the result | Direct reading |
| Correction | 全The range of开路清零功 |
| Charging timer | 999.9s |
| Comparator | 1 set of records,GD/NG |
| Interface | RS-232Interface,可选HandlerInterface |
| Power requirements | Voltage: 198VAC ~ 240VAC Frequency: 50Hz Power: 50VA |
| Size and weight | 445mm(W)x129mm(H)x351mm (D) Weight: 8kg |
