Characteristic
The AT9210A can provide 5kVAC/10mA pressure test
Controllable sine generator: in the AC output can be set to work at 50 or 60Hz, no longer limited by line voltage;
Linear power amplifier: The distortion of voltage waveform is small, simple control and high reliability
40 ~ 600Hz high voltage transformer boost
Output voltage closed-loop control
Carry out AC withstand voltage test independently or multi-item sequential test according to the project setting of the test scheme
Specifications
| Test function | Ac withstand voltage, DC withstand voltage |
| Interface | RS232/Handler |
| Standard configuration | 5kV/10mA |
| Arc detection | Level 9 (AC/DC) |
| Other functions | List Settings
Discharge function 5 "True color LCD touch screen |
| Ac withstand voltage | |
| Rated output | AC 5.000kV/10mA |
| Output voltage | 0.050kV-5.000KV AC
Resolution: 1V |
| Voltage accuracy | 2% of reading + 5 digits |
| Voltage adjustment rate | 2% of reading +5V
(from empty to full) |
| Output frequency | 50Hz or 60Hz -- is optional |
| Measure the current | 0.001mA-10.00mA
Resolution: 0.001/0.01 |
| Current accuracy | 2percent x reading 5 words |
| Voltage rise time | 0.1s-999.9s |
| Test time | 0.2s-999.9s |
| Voltage drop time | 0.1s-999.9s |
| Power requirements | 198V ~ 242V 50/60Hz
400VA |
| Size and weight | 270mm(W)x130mm(H)x450mm (D)
10kg |
| Attachment | ATL900E Voltage test cable,ATL108 communication cable,ATL900E-1 High voltage test rod |
