Characteristic
Channel: 6-way differential, two-way single-ended
8-channel analog input (voltage or current)
Protocol:ASCIl
RS485 communication
Sampling rate :10 sampling points/second
Specifications
| Channel | 8Channel |
| Input range | ±150 mV, ±500 mV, ±1 V, ±5 V, ±10 V, 0~20mA, ±20 mA, 0~150 mV, 0~500 mV, 0~1 V, 0~5 V, 0~10 V |
| Input type | V, mV, mA |
| Resolution (Bits) | 16-bit |
| Sample rate (S/s) | 10 S/s (sum) |
| Mode of communication | RS-485 |
| Isolation voltage | 3,000 VDC |
| Operating temperature | -10~70 °C (14~158 °F) |
| Connector | 2 x 10-pin |
| Protocol | ASCII command |
| Power requirements | 10~30 VDC |
