Characteristic
T/C software configuration, low voltage current input
Isolation voltage: 3000 Vdc
支持Modbus/RTU控制
The value ranges from 4 to 20mA
Line burn detection function
RS485 communication
Specifications
| Channel | 8Channel |
| Input range | mA, T/C: J, K, T, E, R, S, B type |
| Input type | Type J (0~760° C)
Type K (0~1370° C) Type T (-100~400° C) Type E (0~1000° C) Type R (500~1750° C) Type S (500~1750° C) Type B (500~1800° C) ±20 mA, 4~20 mA |
| Resolution (Bits) | 16-bit |
| Sample rate (S/s) | 10 S/s (sum) |
| Mode of communication | RS-485 |
| Isolation voltage | 3000 VDC |
| Operating temperature | -10~70 °C (14~158 °F) |
| Connector | 2 x 10-pin plug-in screw terminal |
| Protocol | ASCII command, Modbus/RTU |
| Power requirements | 10~30 VDC |
