| Specifications | |
| Voltage | |
| Gear position | 5V, 10V, 20V, 40V, 80V, 160V, 320V, 640V A total of 8, automatic/manual shift |
| Measurement type | True effective value |
| Input impedance | >1MΩ |
| 输入Voltage | 1000V (peak value), 700V (effective value) |
| PT ratio setting | 1 ~ 9999 |
| Accuracy (at 23°C 5°C)(sine wave) | +（0.1% 读值 +0.1% Gear position） |
| Current | |
| Gear position | 160mA, 320mA, 640mA, 1.280A, 2.560A, 5.120A, 10.24A, 20.48A a total of 8, automatic/manual shift |
| Measurement type | True effective value |
| Input impedance | 0.01Ω |
| 输入Current | 30A (peak value), 20A (effective value) |
| CT rate setting | 1 ~ 9999 |
| Accuracy (at 23°C 5°C)(sine wave) | +（0.1% 读值+0.1% Gear position） |
| Watt | |
| Measuring range | 0.32mW ~13.10kW |
| Measurement type | True effective value |
| Accuracy (at 23°C 5°C)(sine wave) | +（0.2% 读值+0.2% Gear position） |
| Power factor | |
| The scope of | 0.001 ~ 1.000 |
| The calculation formula | W/(V x A) = Power factor (PF) |
| Frequency | |
| Measuring range | 40Hz ~ 400Hz |
| Accuracy (at 23°C 5°C) (sine wave) | (0.2percent read value 2 bits) |
| The norm | |
| The disy screen | 4 . 0.56"领导;2; 4;领导, |
| Minimum input | 2% Gear position |
| Reaction time | 2 times per second |
| Overload indication | " O.L " |
| Power supply | |
|
|
AC 100V ~ 230V, 50/60Hz |
| Attachment | |
|
|
Power supply线 × 1,操作手册 × 1, |
| 尺寸&重量 | |
|
|
251(W) × 91(H) × 291(L) mm; About 1.6 kg |
