Features:
The cabinet is made of 1mm and 1.2mm high quality steel te, many strengthen the structure, good bearing performance, overlapping structure design, good sealing performance
The surface treatment is made up of 18 processes of orange paint, strong corrosion resistance
Door insert 3.2mm high strength tempered glass, anti front tilting structure design. Integrated design with flat pressure handle lock, anti-theft function. At the bottom of the installation of movable brake casters, easy to move and fixed (anti-static model casters for anti-static)
LED highlighting digital disy, temperature and humidity sensor using the original American brand honeywell, temperature and humidity independent disy, long service life. Humidity can be set and has memory function, no need to set after power off
Humidity disy range of 0percent ~ 99percentRH, temperature disy demonstration
【 Specification Sheet 】
| Picture | The number is | Model number | Specifications | Average power (W) | Maximum power (W) | Overall dimension (mm) | Inside dimension (mm) | Sales
Packing |
RMB(including tax) | Beijing inventory | Shanghai inventory | Japanese inventories | Refer to the delivery date | Query NO. | Optional quantity |
|
CC-2097-01 | CTA98D | The standard type | 13 | 91 | 448×400×688 | 446×372×598 | One | 2,200.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-02 | CTA160D | The standard type | 18 | 126 | 448×450×1010 | 446×422×848 | One | 3,700.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-03 | CTA240D | The standard type | 18 | 126 | 598×400×1310 | 596×372×1148 | One | 4,000.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-04 | CTA320D | The standard type | 20 | 140 | 900×450×1010 | 898×422×848 | One | 4,800.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-05 | CTA435D | The standard type | 20 | 140 | 900×600×1010 | 898×572×848 | One | 5,500.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-06 | CTA540D | The standard type | 20 | 140 | 598×710×1465 | 596×682×1298 | One | 7,000.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-07 | CTA718D | The standard type | 20 | 140 | 598×710×1910 | 596×682×1723 | One | 8,800.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-08 | CTA870D | The standard type | 20 | 140 | 900×600×1890 | 898×572×1698 | One | 9,100.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-09 | CTA1436AD | The standard type | 40 | 280 | 1200×710×1910 | 1198×682×1723 | One | 11,000.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-10 | CTA1436BD | The standard type | 40 | 280 | 1200×710×1910 | 1198×682×1723 | One | 11,000.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-11 | CTA98FD | Antistatic type | 13 | 91 | 448×400×688 | 446×372×598 | One | 2,200.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-12 | CTA160FD | Antistatic type | 18 | 126 | 448×450×1010 | 446×422×848 | One | 3,700.00 | 0 | 0 | 0 | About 15 days | **33 | - |
|
|
CC-2097-13 | CTA240FD | Antistatic type | 18 | 126 | 598×400×1310 | 596×372×1148 | One | 4,000.00 | 0 | 0 | 0 | About 15 days | **33 | - |
|
|
CC-2097-14 | CTA320FD | Antistatic type | 20 | 140 | 900×450×1010 | 898×422×848 | One | 4,800.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-15 | CTA435FD | Antistatic type | 20 | 140 | 900×600×1010 | 898×572×848 | One | 5,500.00 | 0 | 0 | 0 | Six days or so | **33 | - |
|
|
CC-2097-16 | CTA540FD | Antistatic type | 20 | 140 | 598×710×1465 | 596×682×1298 | One | 7,000.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-17 | CTA718FD | Antistatic type | 20 | 140 | 598×710×1910 | 596×682×1723 | One | 8,800.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-18 | CTA870FD | Antistatic type | 20 | 140 | 900×600×1890 | 898×572×1698 | One | 9,100.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-19 | CTA1436AFD | Antistatic type | 40 | 280 | 1200×710×1910 | 1198×682×1723 | One | 11,000.00 | 0 | 0 | 0 | About seven days | **33 | - |
|
|
CC-2097-20 | CTA1436BFD | Antistatic type | 40 | 280 | 1200×710×1910 | 1198×682×1723 | One | 11,000.00 | 0 | 0 | 0 | About seven days | **33 | - |
※ It will take about 18 days to send from Japan if Japan is in storage
Freight charge is extra
※ Catalogue Publishing page: Azovon Experimental Instruments and consumables Catalogue 2019 No. 215
※ Catalog Publishing page: Azovan Experimental Instruments and consumables Catalog 2017 No. 501
