Features:
Eliminate the dead corner of the moisture-proof box, spacious space, can effectively use the space in the box
Adopted a new opening and closing mechanism to eliminate the dead Angle when opening and closing, so it can be set close to the wall
There is no driving device in the new dehumidifier, there is no sound and vibration source, so it has excellent durability
The moisture inside the moisture-proof box is discharged to the outside directly in the state of gas, so there will be no water droplets (condensate)
Specifications:
Dehumidification: The use of solid polymer electrolyte membrane, electrolytic and discharge of water
Humidity setting range :20 ~ 50percentRH(depending on the use of environment)
Humidity control: scale automatic adjustment type (relative humidity)
Dehumidification element effective film area :70×70mm(FN type),50×50mm(BG-FN type)
Shelf size :490×460mm
Shelf installation interval :50mm
Minimum shelf interval :35mm(toughened stic shelf),40mm(stainless steel shelf)
Shelf load :10kg/ sheet (toughened stic shelf),20kg/ sheet (stainless steel shelf)
Power supply :AC100V50/60Hz
Power cord: with 3 plugs long about 2
Accessory :
Tempered stic shelf: SP-SFN-P,SP-BGFN-P,SP-WFN-P / 8 sheets
Stainless steel搁板：SP-SFN-S,SP-BGFN-S、SP-WFN-S／8张
Hygrometer: 1
【 Specification Sheet 】
| Picture | The number is | Model number | Overall dimension (mm) | Internal dimension (mm) | Shelf te quality | Power supply | Sales
Packing |
RMB(including tax) | Beijing inventory | Shanghai inventory | Japanese inventories | Refer to the delivery date | Query NO. | Optional quantity |
|
1-5503-81 | SP-SFN-P | 574×524×1770 | 560×483×1486 | Toughened stics | AC230V | 1 | 14,900.00 | 0 | 0 | 0 | Another query | **13 | - |
|
|
1-5503-82 | SP-SFN-S | 574×524×1770 | 560×483×1486 | Stainless steel | AC230V | 1 | 15,800.00 | 0 | 0 | 0 | Another query | **13 | - |
|
|
1-5503-83 | SP-WFN-P | 1152×524×1770 | 1138×483×1486 | Toughened stics | AC230V | 1 | 26,500.00 | 0 | 0 | 0 | Another query | **13 | - |
|
|
1-5503-84 | SP-WFN-S | 1152×524×1770 | 1138×483×1486 | Stainless steel | AC230V | One | 27,800.00 | 0 | 0 | 0 | Another query | **13 | - |
|
|
1-5503-41 | SP-SFN-P | 574×524×1770 | 560×483×1486 | Toughened stics | AC100V | One | 12,300.00 | 0 | 0 | 0 | About 48 days | **12 | - |
|
|
1-5503-42 | SP-SFN-S | 574×524×1770 | 560×483×1486 | Stainless steel | AC100V | One | 13,000.00 | 0 | 0 | 0 | About 48 days | **12 | - |
|
|
1-5503-43 | SP-WFN-P | 1152×524×1770 | 1138×483×1486 | Toughened stics | AC100V | One | 22,700.00 | 0 | 0 | 0 | About 48 days | **12 | - |
|
|
1-5503-44 | SP-WFN-S | 1152×524×1770 | 1138×483×1486 | Stainless steel | AC100V | One | 23,900.00 | 0 | 0 | 0 | About 48 days | **12 | - |
|
|
H1-5503-41 | SP-SFN-P | 574×524×1770 | 560×483×1486 | Toughened stics | AC220V(including transformer) | One | 12,400.00 | 0 | 0 | 0 | About 48 days | **13 | - |
|
|
H1-5503-42 | SP-SFN-S | 574×524×1770 | 560×483×1486 | Stainless steel | AC220V(including transformer) | One | 13,000.00 | 0 | 0 | 0 | About 48 days | **13 | - |
|
|
H1-5503-43 | SP-WFN-P | 1152×524×1770 | 1138×483×1486 | Toughened stics | AC220V(including transformer) | One | 23,000.00 | 0 | 0 | 0 | About 48 days | **13 | - |
|
|
H1-5503-44 | SP-WFN-S | 1152×524×1770 | 1138×483×1486 | Stainless steel | AC220V(including transformer) | One | 24,200.00 | 0 | 0 | 0 | About 48 days | **13 | - |
※ It will take about 18 days to send from Japan if Japan is in storage
※ Catalogue Publication page: Azovon Experimental Instruments and consumables Catalogue 2019, page 208
