Features:

[Use] can provide a variety of shapes, used for equipment temperature check and cooking utensils and other temperature confirmation, surface temperature detection
[Features] Connect K type thermocouple thermometer to use
Suitable for American OMEGA Company small thermocouple connector (SMP type) (flat electrode central interval 7.9mm)
Available in a variety of shapes, suitable for a variety of purposes

【 Specification sheet 】

Picture	Number	Model	Measuring range (temperature sensing part)	Temperature (℃) Sensor Type	Structure	Sensor cable length	Sensor part size (mm)	销售 Packaging	RMB(tax included)	Beijing inventory	Shanghai inventory	Japanese inventory	Refer to delivery date	Query NO.	Purchase quantity
	61-4672-78	AD-1214	-50~+200	Type K thermocouple	Exposed contact type	About 1m(FEP, Teflon)	Contact part about φ1	1	182.00 155.00	0	0	9		**22	-
	61-4672-79	AD-1215	-50~+700	Type K thermocouple	Insulation type, sheath type (rod type metal protective tube)	About 560(when shrunk, polyurethane)	The metal sheath part is about φ3.2×L150(sheath material SUS304)	1	608.00 517.00	0	0	2		**22	-
	61-4672-80	AD-1217	-50~+500	Type K thermocouple	Exposed type, surface measurement, surface contact part	About 560(when shrunk, polyurethane)	About φ15	1	1,010.00 859.00	0	0	2		**22	-
	61-4672-81	AD-1218-230	-50~+700	Type K thermocouple	Insulation type, sheath type (rod type metal protective tube)	About 1000(silicon)	The metal sheath part is about φ3.2×L230(sheath material SUS304)	1	861.00 732.00	0	0	0	About 25 days	**22	-
	61-4672-82	AD-1218-350	-50~+700	Type K thermocouple	Insulation type, sheath type (rod type metal protective tube)	About 1000(silicon)	The metal sheath part is about φ3.2×L350(sheath material SUS304)	1	993.00 844.00	0	0	3		**22	-
	64-2544-02	AD-1220-100	1	912.00 775.00	0	0	0	23 days or so	**22	-

※ It takes about 18 days to ship from Japan in case of storage in Japan
