Features:

The use of good sealing silicon gasket, no lubricating oil.
Compact size, easy to operate.
Considering the suction problem of the test liquid, the table is equipped with valves and vacuum gauges
With discharge valve, easy to discharge the test liquid.
The sample pressure te is not fixed, so it can also be used as a vacuum moisture-proof box after removal.

Specifications:

Internal size: 260×260×150mm
Material: body/door/acrylic transparent resin (te thickness: 20mm), door gasket/silicone rubber φ8
Allowed vacuum: about 133Pa

Accessories :
Vacuum valve (outer diameter φ8 · φ14 with hose connector × 1 each)
Vacuum gauge
Sample pressure te
Discharge valve

【 Specification sheet 】


Number

Model

Overall dimensions (mm)

Box volume (l)

Sales Packaging

RMB(tax included)

Beijing inventory

Shanghai inventory

Japanese inventory

Refer to delivery date

Query NO.

Purchase quantity

3-6773-01

VRT

300×300×220

About 10

1 set

8,000.00

0

0

9

**13

-

※ It takes about 18 days to ship from Japan in case of storage in Japan

※ Catalog Publication page: Azovan Experimental Instruments and consumables catalog 2019 No. 233

※ Catalog Published page: Azovan Experimental Instruments and consumables catalog 2017 No. 519
