LDA15F Series COSEL Power Supply LDA15F-24 LDA15F- 12 LDA15F- 15 LDA15F- 5 LDA15F- 3
Rated input: AC85-264V1Φ
Rated output power: 15W
Rated output voltage: 3V,5V,12V,15V,24V
RoHS指令
UL ・ C-UL CSA TUV CE
Warranty period of 2 years
The power supply is made of SMD. Stress such as twisting or bending on the P.C.B will cause damage to the unit, so please handle the unit carefully
LDA15F features
• Robust PCB type (CEM3)
• Input range
LDA10-75F（AC85-264V）
LDA100-300W（AC85-132V / AC170-264V）
Automatic range input
• Built-in inrush current, overcurrent and overvoltage protection circuits
Ordering information and options
LDA（1）15（2）F（3）-5（4）-□（5）
（1）Series名称
(2) Output power
(3) Universal input
(4) Output voltage
(5) Optional *
C: With coating
G: Low leakage current
S: With chassis
SN: With case and cover
Y: With potentiometer
* Please get the model with optional.
Hoonan Electronics The EMI filter NAC-06-472
Pressure pulse noise type: NAP-04-472
Low leakage current type: NAM-04-472
* In view of other devices that may be in parallel with the power supply, EMI/EMC filters with rated current are recommended.
Product Line-up
COSEL Power SupplyLDA15F-24 LDA15F-12
Product Name |
Output Wattage |
Output Voltage･Current |
LDA15F-3 |
9W |
3V 3.0A |
LDA15F-5 |
15W |
5V 3.0A |
LDA15F-12 |
15.6W |
12V 1.3A |
LDA15F-15 |
15W |
15V 1.0A |
LDA15F-24 |
16.8W |
24V 0.7A |
* For further information and how to use, please see in Cosel product catalog.
For industrial or civil electronic equipment, a lot of electronic components based on semiconductor products need to be used
IC (integrated circuit),FET (field effect transistor), transistor, diode and other semiconductor products, which must provide stable direct current to make them work normally
In other words, the conversion of alternating current from power nts to individual factories or households into stable direct current is an important step
And to achieve this transformation, it is the DC regulated power supply of Corso.
Hoonan Electronics的COSEL开关电源因其体积小,质量轻,效率等特点,被使用于以通信设备、设备和工业自动化设备为的电子设备上.
The switching power supply using the semiconductor speed switch is the main product of Corso.
Corso has a 50-year history and occupies the * -- in Japan switching power supply
In addition, since 2005, Corso has been producing filters for the protection of electronic devices from noise.
Now, around the social development and life of the products, the vast majority have been electronic, which is an important switching power supply, can be said to be the key to development and progress
For Corso, it is our mission as always to continue to explore the new and produce the products that build the electronic future.
