Product specifications: Fluke 301D AC-DC blade series clamp table
Product specifications
Accuracy is applicable for one year after calibration, operating temperature is 18 °C to 28 °C, relative humidity is 0 percent to 75 percent. The precision specification shall be in the following form:
±([percent of reading] [least significant digit value]).
| Model number | 301A/A+ | 301B | 301C | 301D | ||||||
| Ac current (45 to 400 Hz) | The range of | 40.00A | 400.0A | 60.00A | 600.0A | 60.00A | 600.0A | 1000A | 60.00A | 600.0A |
| Resolution | 0.01A | 0.1A | 0.01A | 0.1A | 0.01A | 0.1A | 1A | 0.01A | 0.1A | |
| Precision | 2%+10 | 2%+5 | 2%+10 | 2%+5 | 2%+10 | 2%+5 | 2%+5 | 2%+10 | 2%+5 | |
| Direct current | The range of | - | - | - | 60.00A | 600.0A | ||||
| Resolution | 0.01A | 0.1A | ||||||||
| Precision | 2%+10 | 2%+5 | ||||||||
| Ac voltage (45 to 400 Hz) | The range of | 600.0V | 600.0V | 600.0V | 600.0V | |||||
| Resolution | 0.1V | 0.1V | 0.1V | 0.1V | ||||||
| Precision | 1.5%+5 | 1.5%+5 | 1.5%+5 | 1.5%+5 | ||||||
| Dc voltage | The range of | 600.0V | 600.0V | 600.0V | 600.0V | |||||
| Resolution | 0.1V | 0.1V | 0.1V | 0.1V | ||||||
| Precision | 1%+5 | 1%+5 | 1%+5 | 1%+5 | ||||||
| Resistance | The range of | 600.0Ω
6.000kΩ 60.00kΩ |
600.0Ω
6.000kΩ 60.00kΩ |
600.0Ω
6.000kΩ 60.00kΩ |
600.0Ω
6.000kΩ 60.00kΩ |
|||||
| Precision | 1%+5 | 1%+5 | 1%+5 | 1%+5 | ||||||
| Voltage frequency | The range of | 9.999Hz
99.99Hz 999.9Hz 9.999kHz 99.99kHz |
9.999Hz
99.99Hz 999.9Hz 9.999kHz 99.99kHz |
9.999Hz
99.99Hz 999.9Hz 9.999kHz 99.99kHz |
9.999Hz
99.99Hz 999.9Hz 9.999kHz 99.99kHz |
|||||
| Precision | 0.1%+3 | 0.1%+3 | 0.1%+3 | 0.1%+3 | ||||||
| Current frequency | The range of | 45.0-400.0 Hz | 45.0-400.0 Hz | 45.0-400.0 Hz | 45.0-400.0 Hz | |||||
| Precision | 0.1%+3 | 0.1%+3 | 0.1%+3 | 0.1%+3 | ||||||
| Capacitance | The range of | 9.999uF | 99.99uF 999.9uF | 9.999uF | 99.99uF 999.9uF | 9.999uF | 99.99uF
999.9uF |
9.999uF | 99.99uF 999.9uF | |
| Precision | 2%+5 | 5%+5 | 2%+5 | 5%+5 | 2%+5 | 5%+5 | 2%+5 | 5%+5 | ||
| Diode | 3.000V | 3.000V | 3.000V | 3.000V | ||||||
| 10% | 10% | 10% | 10% | |||||||
| True effective value | - | - | - | |||||||
| On and off | ||||||||||
| Data retention | ||||||||||
| Backlight | - | |||||||||
| The CAT level | CAT III 300V | CAT III 300V | CAT III 300V | CAT III 300V | ||||||
| Fuselage weight | 132g | 132g | 132g | 154g | ||||||
| Fuselage size | 190 mm x 52 mm x 16 mm | 190 mm x 52 mm x 16 mm | 190 mm x 52 mm x 16 mm | 190 mm x 52 mm x 16 mm | ||||||
| Jaw opening | 34mm | 34mm | 34mm | 34mm | ||||||
| Clamp arm size | 10mmX10mm | 10mmX10mm | 10mmX10mm | 10mmX10mm | ||||||
| Battery | Section 2 AAA | Section 2 AAA | Section 2 AAA | Section 2 AAA | ||||||
| Quality assurance | 1 year | 1 year | 1 year | 1 year | ||||||
General technical index
| The highest voltage between any terminal and ground | 300 V |
| V/Ω 端子和 COM 端子间的差分电压 | 600 V |
| Disy screen (LCD) | 6000 counts, updated 3 times per second |
| Battery类型 | 2 AAA, IEC LR03 |
| Battery寿命 | Minimum 500 hours |
| Automatic shutdown time | Twenty minutes |
| Temperature | 工作Temperature：-10 °C 至 50 °C; |
| 存放Temperature： -30 °C 至 60 °C | |
| Relative humidity | 工作湿度：非冷凝 (低于 10 °C 时); 10 °C 至 30 °C 时,Relative humidity ≤ 90 %;30 °C 至 40 °C 时,Relative humidity ≤ 75 %;40 °C 至 50 °C 时,Relative humidity ≤ 45 %; |
| Altitude | 工作Altitude： 2000 m;存放： 12000 m |
| Temperature系数 | 0.1 X (Precision)/°C (<18°C或>28 °C) |
| Volume (height x width x length) | 190 mm x 52 mm x 16 mm |
| The weight of | 132 g (301D 154g) |
| Jaw opening | 34 mm |
| IP level | IP30 |
| Security | IEC 61010-1,IEC61010-2-032 CAT III 300 V, pollution level 2 |
| Electromagnetic environment | IEC 61326-1: Portable |
