Product specifications: Fluke 373 true RMS ac clip-on (type) table | clip-on ammeter...
| Electrical technical specification | |
| Alternating current | |
| The range of | 600.0 A |
| Resolution | 0.1 A |
| Accuracy | 2%±5‰(48 - 62赫兹)—— |
| Crest factor (50/60 Hz) | 2.5(600a / h)—— |
| Alternating current压 | |
| The range of | 600.0 V |
| Resolution | 0.1 V |
| Accuracy | 1.0%±5‰(48 - 62赫兹)—— |
| Dc voltage | |
| The range of | 600.0 V |
| Resolution | 0.1 V |
| Accuracy | 1 percent ± 5 digits |
| Resistance | |
| The range of | 600.0 Ω/6000 Ω |
| Resolution | 0.1 Ω/1 Ω |
| Accuracy | 1 percent ± 5 digits |
| On/off test buzzer | 30 Ω |
| Capacitance | |
| The range of | 10.0 – 100.0 μF/1000 μF |
| Resolution | 0.1 μF/1 μF |
| Accuracy | 1.9%±2‰—— |
| Mechanical specifications | |
| Dimensions (length x width x height) | 232 mm x 85 mm x 45 mm |
| The weight of | 370 g |
| Environmental indicators | |
| Operating temperature | -10°c - 50°c |
| Storage temperature | -40°c - 60°c |
| Operating humidity | Non-condensing (< 10 °C)
≤90% RH(10°C - 30°C)—— ≤75% RH(30°C - 40°C)—— ≤45% RH(40°C - 50°C)—— (non-condensing) |
| Working altitude | 3000 meters |
| Storage elevation | 12000 meters |
| EMI, EMC | Meet all relevant requirements in EN61326-1:2006 |
| Temperature coefficient | 大于 28°C,低于 18°C,每度加上 0.1× 规定Accuracy |
| Meet safety standards | ANSI/ISA S82.02.01:2004
CAN/CSA-C22.2 No. 61010-1-04 Iec / en 61010-1:2001, 600v cat iii和300v cat iv—— Pollution level 2 EN/IEC 61010-2-32:2002 EN/IEC 61010-031:2002/A1:2008 |
| Institutional certification |
|
| Battery | 2 AA,NEDA 15A,IEC LR6 |
