Product specifications: Fluke 1630-2 FC grounding loop resistance tester
| Electrical technical specifications | ||
| Maximum ground voltage | 1000 V | |
| Battery type | AA碱IEC/EN LR6 (x4)—— | |
| Battery life | More than 15 hours * | |
| * In ground resistance measurement mode, backlit light and RF mode are off | ||
| Frequency range | 40hz - 1 kHz | |
| Protection level | IEC/EN 60529: IP30 (jaws closed) | |
| LCD disy | Digital reading | 9999 counts |
| Refresh rate | 4/ s | |
| Operating temperature | -10°c - 50°c |
|
| Storage temperature | -20°c - 60°c | |
| Operating humidity | Non-condensing (< 10 °C) (< 50 °F) | |
| ≤90% RH(在10°C至30°C(50°F至86°F)时)— | ||
| ≤75% RH(在30°C至40°C(86°F至104°F)时)— | ||
| ≤45% RH(在40°C至50°C(104°F至122°F)时)— | ||
| （非冷凝） | ||
| Working altitude | 2000 m (6561 feet) | |
| Storage elevation | 12 000 m (39,370 feet) | |
| Reference temperature | 23 °C ±5 °C (73 °F ±9 °F) | |
| 温度系数 | 0.15% x（精度）/ °C（<18 °C 或 >28 °C [<64.4 °F 或 >82.4 °F]） | |
| Overload indication | OL | |
| Data record capacity | At least 32,760 measurements | |
| Data recording interval | 1 second to 59 minutes and 59 seconds | |
| Disys standard loop resistance reading specifications | ||
| Enter (Ω) | The smallest | Maximum |
| 0.474 | 0.417 | 0.531 |
| 0.5 | 0.443 | 0.558 |
| ="10" | 9.55 | 10.45 |
| ="100" | ="96" | ="104" |
| Security | ||
| General | IEC/EN 61010-1:2 Level Pollution IEC/EN 61557-1 | |
| Measure | IEC/EN 61010-2-032：CAT IV 600 V / CAT III 1000 V | |
| 用于漏电流Measure的电流钳表 | IEC/EN 61557-13:2，≤30a /m | |
| Ground resistance | IEC/EN 61557-5 | |
| The effectiveness of protective measures | IEC/EN 61557-16 | |
| Electromagnetic compatibility (EMC) | International standard | IEC/EN 61326-1: Portable Electromagnetic Environment |
| Cispr 11:1 gb / s, iec / en 61326-2-2— | ||
| Korea (KCC) | Category A Equipment (Industrial broadcasting and communications equipment) | |
| The United States (FCC) | 47 CFR 15 B subpart. This product is deemed to be duty-free equipment in accordance with Clause 15.103 | |
| Radio | ||
| Frequency range | 2412 MHz--- 2462 MHz | |
| Output power | <10 mW | |
| Radio频率 | FCC ID:T68-FBLE IC:6627A-FBLE | |
| General技术指标 | ||
| Conductor specification | 40毫米(1.57英寸)—— | |
| Dimensions (length x width x height) | 283 x 105 x 48 mm (11.1 x 4.1 x 1.9 in) | |
| The weight of | 880g (31 oz) | |
| Warranty period | 1 year | |
| Grounding loop resistance | ||
| The range of | 精度="1" ± (± percent of the reading value) | |
| 0.025 Ω 0.00.249 Ω—— | 1.5% + 0.02 Ω | |
| 0.250 Ω |
1.5% + 0.05 Ω | |
| 1.000 Ω清洁度9.999 Ω—— | 1.5% + 0.10 Ω | |
| 10.00 Ω清洁度49.99 Ω—— | 1.5% + 0.30 Ω | |
| 50.00 Ω清洁度99.99 Ω—— | 1.5% + 0.50 Ω | |
| 100.0 Ω 199.9 Ω—— | 3.0% + 1.0 Ω | |
| 200.0 Ω清洁度399.9 Ω—— | 5.0% + 5.0 Ω | |
| 400 Ω to 599 Ω | 10.0% + 10 Ω | |
| 600 Ω to 1500 Ω | 20.00% | |
| ="1" Loop resistance no inductance, conductor centered and perpendicular to the pliers | ||
| 接地漏电流Measure mA | ||
| 自动The range of 50/60 Hz,真有效值,波峰系数 CF ≤3 | ||
| The range of | Resolution | 精度="1" ± (± percent mA of read value) |
| 0.200 mA- 3.999 mA | 1 μA | 2.0% + 0.05 mA |
| 4.00毫安--- 39.99毫安 | 10 μA | 2.0% + 0.03 mA |
| 40.0 mA--- 399.9 mA | 100 μA | 2.0% + 0.3 mA |
| 0.400 a - 3.999 a | 1 mA | 2.0% + 3 mA |
| 4.00 a - 3.99 a | 10 mA | 2.0% + 30 mA |
="1"
Applicable signal frequency
|
||
