Product specifications: Fluke PTi120 portable pocket thermal imager
| 关键功能 | |
|---|---|
| IFOV（空间分辨率） | 7.6 mRad |
| Infrared resolution | 120 x 90 (10,800 pixels) |
| Field of view | 50° H x 38° V |
| The distance coefficient ratio | 130:1 |
| Temperature measurement range (uncalibrated below -10°C) | -20°c - 400°c |
| Focusing system | Fixed focal length, minimum focal length 22.8cm |
| USB | Micro USB, used to transfer images to PC |
| Wifi | It is |
| Fluke Connect® Instant Upload | Yes, by connecting the thermal imager to the WiFi network in the building, the image is automatically taken and uploaded to the Fluke Connect® system or your local server for storage and viewing on your PC (802.11 bgn (2.4 GHz)) |
| 图像质量 | |
|---|---|
| IR-Fusion 可见光融合技术 | Yes, adding visual detail to infrared images |
| AutoBlend Mode. Autoblend Mode | Consecutive 0percent to 100percent |
| Touch screen | 3.5 inch (landscape),320 x 240 LCD |
| Rugged ergonomic design | It is |
| Thermal sensitivity (NETD) | 60 mK |
| Frame rate | 9 Hz |
| 数据存储和图像捕捉 | |
|---|---|
| 存储器 | ≥ 2GB internal flash memory |
| Image capture, view, save mechanism | One - hand image capture, view and save functions |
| Image file format | Non-radiation measurement (jpeg) or full radiation measurement (.is2); No analysis software is required for non-radiometric (jpeg) files |
| Software | Fluke Connect® 桌面Software - 可访问 Fluke Connect 系统的全面分析和报告Software |
| 使用Software导出文件格式 | JPG、IS2 |
| Measuring range | -20 °C~400 °C |
| 电池 | |
|---|---|
| 电池（可充电） | Built-in rechargeable lithium-ion battery. |
| Battery life | For more than 2 consecutive hours (without WiFi) |
| Battery charging time | ≤ 1.5 hours |
| Battery charging system | Micro USB cable connects from product to PC |
| Alternating current operation | Use a separate AC-USB adapter. It does not come with the box |
| Energy saving | Automatic shutdown:
5,10,15 and 20 minutes or never |
| 温度测量 | |
|---|---|
| Temperature measurement range (uncalibrated below -10°C) | -20°c - 400°c |
| Precision | 0 °C或以上的目标温度：Precision：± 2 °C 或 ± 2% |
| Screen emissivity correction | It is |
| The screen disys adjustable background temperature compensation | It is |
| 调色板 | |
|---|---|
| 标准调色板 | 6: Iron red, blue red, high contrast, amber, hot metal, gray |
| 一般技术指标 | |
|---|---|
| 红外波长 | 8 μm to 14 μm (long wave) |
| Operating temperature | -10°c - 50°c |
| Storage temperature | -40°c - 70°c(-40°f - 158°f |
| Relative humidity | 95%无冷凝 |
| Center point temperature | It is |
| Point temperature | Hot and cold spot markers |
| Security | EN 61010-1: Non-CAT, pollution level 2,EN 60825-1:2 Class,EN 60529,EN 62133 (Lithium batteries) |
| Electromagnetic compatibility | EN301 489-1 V2.1.1 EN301489-17 V3.1.1 |
| US FCC | CFR, Part 15C |
| Vibration and shock | 2g, iec 68-2-6; 25g, iec 68-2-29—— |
| Fall off | 1 米Fall off |
| Dimensions (height x width x length) | 8.9 cm x 12.7 cm x 2.5 cm
(3.5 in x 5.0 in x 1.0 in) |
| Weight (including battery) | 0.233 kg (0.514 lb) |
| Shell protection class | IP54 |
| Warranty life | Two years |
| Supported languages | Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish |
