Product specification: Fluke-154 Calibration communicator
| A tablet computer | |
| Operating system | Android 5.0 or later |
| Processor | ARM、Atom—— |
| Memory RAM | 1 GB |
| Memory ROM | 2 GB |
| The screen | 960x540 qHD |
| Communication port | Bluetooth |
| HART modem | |
| The shell | |
| Material | High strength ABS stics |
| Size | 10.16 x 2.5 x 6.9 cm (4 x 1 x 2.75 in) |
| Total weight of equipment | 0.16 kg (0.36 lbs) |
| Cable | |
| HART Cable长度 | 4 ft (1.2 m) |
| HART CableConnect器 | Mini grappling hook |
| HART interface | |
| Interface | Capacitive coupling |
| Output | 600 mVpp |
| Leakage of electricity | <10 uA |
| Connect | Cross-loop resistors or HART field equipment |
| Technical specifications | HART 4、HART 5、HART 6、HART 7 |
| HART Physical Layer Specification | HCF_SPEC-54 |
| Bluetooth | |
| Technical specifications | Bluetooth v2.0 |
| Frequency | 2.4 GHz |
| Class 1 main distance | 83.8 m (275 ft) |
| Battery | |
| Type | 可充电锂离子Battery |
| Working hours | Continuous use of 19 hours |
| Environment | |
| Operating temperature | 0°c - 50°c(32°f - 122°f |
| Storage temperature | -10°c - 45°c(-14°f - 113°f |
| Humidity | 0percent to 90percent (no condensation) |
